TL_PS Blink Code

POWER SUPPLY VOLTAGE ERROR (Top Load Washer) Cause The supply voltage is not correct. Solution If unit wont power up, check the power source, the unit will need 120Vac (+/- 5%), and correct polarity. DETAILS BELOW: After you have verified power supply from outlet, make sure you have 120Vac into and out of Filter board, […]

TL_UE Blink Code

UNBALANCED ERROR CODE Cause The unit is not properly leveled. Solution Level the unit making sure the drum is centered properly. Cause The load is too small. Solution Add additional items to allow the washer to balance the load. Cause Heavy articles are mixed with lighter items. Solution Always try to wash articles of somewhat […]

TL_PE Blink Code

PRESSURE SWITCH ERROR (Top Load Washer) Cause Water Pressure Sensor isn’t working properly. Solution Make sure that the Pressure Sensor, connections are good at sensor, and main board. Check for oversudsing issues, if unit is in this condition, advise to run tub clean with a cleanser, such as, Affresh®  DETAILS BELOW: Check the pressure sensor […]

TL_OE Blink Code

OUTLET WATER ERROR (Top Load Washer) Cause Drain hose is kinked, pinched, or clogged. Solution Make sure that the drain hose is free of clogs or kinks and is not pinched behind or under the washer. Cause The end of the drain hose is more than 96 inches above the bottom of the washer. Solution Move […]

TL_LE Blink Code

LOCKED ROTOR ERROR Cause  The motor can not turn Solution   Check for tub moving freely by hand and if does not may it be a bad clutch assembly. Check for a foreign item between the tubs. If it does move freely check for cracked magnets on the rotor. The stator windings may have resistance values […]

TL_IE Blink Code

INLET ERROR The Main PCB does not detect that any (or not enough) water has flowed into the tub based off the pressure sensor frequency. Cause Water supply faucets are not fully open, or low water pressure. Water inlet hoses are kinked, pinched, or crushed. Solution Make sure that the water faucets are fully open. […]

TL_FE Blink Code

OVERFILL ERROR Cause Water level too high Solution Make sure that the water valve isn’t stuck. Be sure the customer is not using too much detergent causing an excess of suds and foam. The detergent should be High Efficiency detergent to reduce the possibility of over sudsing issues that interfere with the pressure sensor reading. […]

TL_E6 Blink Code

CLUTCH MOTOR ERROR Cause The Main PCB is not detecting the correct signal voltage from the clutch motor when engaging or disengaging the clutch. Solution If a clicking or grinding noise is made, disassemble the pulsator and tub to check for any foreign objects (coins, keys, hair pins, etc). If a foreign object is found, […]

TL_DR Blink Code

DRAIN FEATURE (NOT AN ERROR CODE) “dr” is a special drain feature If the washer is paused during a cycle for more than 4 minutes, the cycle will be canceled and any water remaining in the tub will be drained. This is not an error code. It indicates that the drain function is operating.
